DC voltage range: 48Vdc

  Peak Power 3.6kW @2500rpm

  Nominal Power 2.5 kW@2500rpm

  Motor Dimension: Ø 240 mm X 128 mm

  Weight: 7.5k

  DC Voltage: 48 Volt

  Max Rms current @ 3.6 kW : 77 Amp

  Nominal Rms current @ 2.5 kW: 49 Amp

  Max Bat current: 75 Amp

  Moto Control modes: Field Oriented Sinusoidal Control

  Sensor Types: Sine / Cosine Magnetic Encoder

  Control Interface: Isolated CAN-Bus or Inputs from Vehicle control units

  Protection: Over-current, Short-circuit, Under/Over-voltage, Stall & Over-Speed
