DC voltage range: 48Vdc

  Peak Power 8 kW @2500rpm

  Nominal Power 12 kW@2500rpm

  Motor Dimension: Ø 306 mm X 160 mm

  Weight: 15.5 kG

  DC Voltage: 48 Volt

  Max Rms current @12 kW : 268 Amp

  Nominal Rms current @ 8 kW: 174 Amp

  Max Bat current: 250 Amp

  MotControl modes: Field Oriented Sinusoidal Control

  Sensor Types: Sine / Cosine Magnetic Encoder

  Control Interface: Isolated CAN-Bus or Inputs from Vehicle control units

  Protection: Over-current, Short-circuit, Under/Over-voltage, Stall & Over-Speed
