DC voltage range: 100 Vdc

  Peak Power 16 kW @3200 rpm

  Nominal Power 5 kW @2000 rpm

  Max Operating speed: 3600 rpm

  Motor Dimension: Ø 152.7 mm X 124 mm

  Shaft Dia: Ø 15 mm

  Weight: 4.2Kg

  DC voltage range: 100 Vdc

  Max Rms current @ 16kW: 165 Amp

  Nominal Rms current @ 5kW: 100 Amp

  Max Bat current: 160 Amp

  Moto Control modes: Sensor-less BLDC Trapezoidal / Field Oriented

  Sinusoidal Control modes

  Control Interface: PWM signal (RC servo), Isolated CAN-Bus

  Protection: Over-current, Short-circuit, Under / Over-voltage, Stall & OverSpeed
