DC voltage range: 44 Vdc

  Peak Power 1.9 kW @5200 rpm

  Nominal Power 1kW @ 4000 rpm

  Max Operating speed: 5600 rpm

  Motor Dimension: Ø 60 mm X 52 mm

  Shaft Dia: Ø 4 mm

  Weight: 1.18 Kg

  DC voltage range: 44 Vdc

  Max Rms current @ 1.9kW : TBD Amp

  Nominal Rms current @ 1.0 kW: TBD Amp

  Max Bat current: TBD Amp

  Moto Control modes: Sensor-less BLDC Trapezoidal / Field Oriented Sinusoidal Control modes

  Control Interface: PWM signal (RC servo), Isolated CAN-Bus

  Protection: Over-Current, Short-circuit, Under/Over-voltage, Stall & OverSpeed
